siplace adagoló szenzorral 2x8mm 00141289

ASM SMT 2X8MM Feeder (Model 00141289) is an electronic component feeding device for SMT production lines. Its working principle is based on:

Electrically driven, the material belt is advanced by a precision stepper motor

The sensor detects the component position and feeding status

The mechanical structure realizes accurate positioning and feeding of 8mm wide carrier tape

The dual-channel (2X) design can handle two rolls of components at the same time, improving production efficiency

II. Product Features

Mechanical structure features:

Compact design, saving production line space

Modular structure, easy maintenance and replacement of parts

Precision guide rails ensure feeding stability

Electrical features:

High-precision photoelectric sensor detects component position

Programmable control of feeding step length

With self-diagnosis function

Operation features:

Humanized operation interface

Quick replacement of carrier tape design

Compatible with a variety of 8mm Packaged components

III. Product features Product advantages

Magas hatásfok:

Dual-channel design to improve feeding speed

Fast response time (<100ms)

High precision:

Feeding accuracy can reach ±0.05mm

High repeatability:

High reliability:

Mean time between failures (MTBF)>10,000 hours

High-quality materials to ensure long-term stable operation

Kompatibilitás:

Support a variety of 8mm wide carriers

Compatible with a variety of ASM placement machines

IV. Precautions for use

Installation precautions:

Ensure that the feeder and the placement machine interface are connected correctly

Check whether the power connection is firm

Confirm that the grounding is good

Operation precautions:

Before installing the carrier, please check whether the carrier is deformed or damaged

Ensure that the component spacing is set correctly

Avoid overload operation

Safety precautions:

Please turn off the power for maintenance before operation

Do not forcibly remove components during operation

Keep the work area clean

V. Common error messages and solutions

Error code Error description Possible cause Solution

E001 Feeding failure Carrier stuck/motor failure Check carrier path/restart device

E002 Sensor abnormality Photoelectric sensor dirty/damaged Clean sensor/replace sensor

E003 Communication error Loose connection line/interface failure Check connection/replace connection line

E004 Timeout error Feeding resistance is too large Check carrier tension/lubricate guide rail

E005 Position deviation Loose mechanical structure Check and tighten related parts

VI. Maintenance method

Napi karbantartás:

Clean the surface and guide rail of the feeder daily

Check whether the sensor is clean

Győződjön meg arról, hogy az összes rögzítőelem nincs kilazult

Regular maintenance:

Add lubricant to moving parts every month (use specified lubricant)

Check the motor status every quarter

Perform a full calibration every six months

Long-term storage recommendations:

Store in a dry environment after cleaning

Power on regularly to prevent circuit aging

Apply anti-rust oil to important parts

Replacement cycle of wearing parts:

Feeding gear: about 500,000 times

Photoelectric sensor: about 2 years or depending on usage Depends

Transmission components: about 1 year or depending on wear and tear

VII. Technical parameters

Model: 00141289

Applicable carrier width: 8mm

Number of channels: 2

Feeding accuracy: ±0.05mm

Maximum feeding speed: 300 components/minute (per channel)

Power requirement: 24VDC±10%

Power consumption: <50W

Operating temperature: 15-35°C

Storage temperature: -10-60°C

Weight: about 2.5kg

Dimensions: 150×80×60mm (length×width×height)

Through proper use and maintenance, ASM 2X8MM feeder 00141289 can provide a stable and reliable supply of components for SMT production lines, significantly improving production efficiency and product quality.
